| RF Input Options |
| Satellite Input Option |
| Number of Inputs | 1 x RF Input, 1 x RF Loop Out |
| Connector Type | F-Type (Female, 75Ω) |
| Standards | DVB-S/S2 (EN 300 421/EN 302 307) |
| Constellations | DVB-S: QPSK, DVB-S2: QPSK/8PSK |
| Frequency Range | 950MHz to 2150MHz |
| Input Signal Level | -65 to -25dBm |
| LNB Power Output | 0V/+DC 13V/18V, Imax=400mA |
| Cable Input Option |
| Number of Inputs | 1 x RF Input, 1 x RF Loop Out |
| Connector Type | F-Type (Female, 75Ω) |
| Standards | DVB-C (EN 300 429) |
| Constellations | 16/32/64/128/256 QAM |
| Frequency Range | 51 to 858MHz |
| Input Signal Level | -20 to +20dBm (64QAM) |
| ASI Transport Stream Input |
| Numbers of Interface | 1 x ASI Input, 1 x ASI Loop Out |
| Connector Type | BNC (Female, 75Ω) |
| Data Format | 188/204 Bytes MPEG-TS packet length |
| Bit Rate | 1.5 to 100 Mbps each |
| MPEG TS-over-IP Output |
| Numbers of Output | 1 x 10/100 Base-T Ethernet, RJ-45 |
| MPEG TS Format | 7 x 188Byte |
| IP Encapsulation | MPEG TS-over-UDP/IP |
| Number of TS Output | 1 x MPTS |
| Addressing | Unicast or Multicast |
| Supported Protocol | UDP, ARP, ICMP, IGMP |
| ASI Transport Stream Output |
| Numbers of Interface | 2 x ASI |
| Connector Type | BNC (Female, 75Ω) |
| Operation Mode | Can be configured to pass through output, descrambling output or matrix output depending on different settings |
| Input Mode | Independent or redundant output |
| Data Format | 188/204 Bytes MPEG-TS packet length |
| Bit Rate | Up to 100Mbps output (72Mbps after descrambling) |
| Operation Mode of TS Input/Output |
| RF and ASI Input | Alternatively |
| ASI and IP Output | Simultaneously (with same TS) |
| DVB-CI & TS Descrambling |
| Numbers of DVB-CI | 2 x CI Slots (in front panel) |
| Interface Type | PCMCIA Type II |
| CI Standard | Comply with EN 50221 |
| Rate of Descrambling | 72Mbps per CAM |
| Performance | Up to 16 programs simultaneously |
| Supported CA Category | DVB SimulCrypt and MultiCrypt |
| Audio/Video Decoding Output |
| Composite Video | 1 x CVBS(BNC female, 75W) |
| Component Video | 1 x YPbPr(BNC female, 75W) |
| Unbalanced Audio | 1 x Stereo pairs (BNC female, 600W) R&L, Stereo or Mono mode |
| HDMI | 1 x HDMI 1.3 (Type A receptacle) |
| Video Decoding |
| Decoding Formats | MPEG-2 SD: MP@ML, HD: MP@HL MPEG-4 AVC SD: MP@L3, HD: HP@L4 |
| Resolution& Frame Rate | SD: 480i@30fps, 576i@25fps HD: 1080i@25/30fps, 720P@50/60fps |
| Aspect Ratio | 4:3 or 16:9 |
| Video Decoding Rate | 0.5 to 20Mbps |
| Audio Decoding |
| Decoding Standards | MPEG-1 Layer 2 |
| Optional: AAC |
| Operation Mode | Stereo or Mono |
| Supported Sample Rate | 32 kHz, 44.1 kHz, 48 kHz |
| Audio Decoding Rate | 64kbps to 384 kbps |
| Miscellaneous |
| Front Panel Management and Control | 3.5’’ LCD with 7 x Control Buttons, for 2-line display and OSD control |
| 3 x Dual color LED, for status indications of power, work and Alarm |
| Rear Panel | 1 x USB 2.0 for firmware update |
| 1 x Serial Console Port(RS-232, DB-9) |
| 1 x Power Supply Receptacle (AC Input) |
| 1 x Power switch |
| Power Supply |
| Input Voltage | 110 - 240 VAC, 50/60Hz |
| Power Consumption | 50W(Maximum) |
| Environmental |
| Operating Temperature | 0℃ to 45℃(32℉ to 113℉) |
| Storage Temperature | -20 to 80℃(-4℉ to 176℉) |
| Operating Humidity | 90%, non-condensing |
| Mechanical |
| Product Dimensions (W x H x D) | 483mm x 44.5mm x 300mm 19’’ x 1.73’’ (1 RU) x 11.8’’ |
| Product Weight | 3Kg (6.6 lbs) |
